BWC40-04H Autonics Area Sensor | Industrial Automation Sensor | KMSPARE

Type Light Sensor Detection Range 2 meter Accuracy 100 % Activation current 15 mA Active Area 7 m Operating temperature -10 ........+55 C Power Supply 12 - 24 V Sensing distance 1 - 7 m Protection IP67 Response time 50 ms Weight 2.1 kg Cablr Length 2 m BWC40-04H Sensing type : Through-beam type(cross beam) Sensing distance : 1 to 7m Light source : Infrared LED(850nm modulated) Optical axis pitch : 40mm Number of optical axes : 4 Power supply : 12-24VDC ±10%(ripple P-P: max. 10%) Control output : NPN open co
