DOP-B10S615 Delta HMI | 10.1" Human Machine Interface | KMSPARE

Mounting Type Panel Mount Screen size 12 inch Display Size 22 inch Resolution 1024 x 768 Pixels Control Type Touch Screen Dimensions (W) x (H) x (D) mm 272 x 200 x 61 Display Colors 65k Memory 800 Dimension 261.3 X 189.3 Model No. DOP-B10S615 Brand Delta Product Type HMI Color Black Protection IP65 Weight 1520 g Operation Temp. 0 ...... 50 C The half-life of backlight is defined as original luminance being reduced by 50% when the maximum driving current is supplied to HMI. The life of LED backlight shown here is an estimated value under 25oC normal temperature and humidity conditions. 2) USB Host port can provide up to 5V/ 500mA of power. 3) The withstand voltage of the isolated power circuit is 1500V peak for 1 minute. 4) Some models are in the process of application to UL and KCC certification. For more information, please consult our distributors. 5) The value of the power consumption indicates the electrical power consumed by HMI only without connecting to any peripheral devices. In order to ensure the normal operation, it is recommended to use a power supply which the capacity is 1.5 ~2 times the value of the power consumption. 6) The content of this quick start may be revised without prior notice. Please consult our distributors or download the most
