DPC-101-P Panasonic Digital Pressure Sensor | High-Accuracy Industrial Sensor | KMSPARE

Suitable Media Gas Brand Panasonic Pressure Range 50 Bar Accuracy 100 % Response Time 5 ms Output PNP Supply Voltage 12 - 24 V Interface I/O Link Housing Material Plastic Operating Temperature -25 to 70 Deg C IP Protection Class IP67 Model No. DPC-101-P Product Type Digital Pressure Sensor Weight 140 g CE Marking Directive Compliance EMC Directive, RoHS Directive Type of Pressure Gauge pressure Rated Pressure Range DPH-101?(Compound pressure): -100.0 to +100.0 kPa, DPH-102?(Positive pressure): 0 to +1.000 MPa, DPH-103?(Vacuum pressure): 0 to -101.0 kPa (Note) : It changes automatically according to the connected pressure sensor head. Set Pressure Range DPH-101?(Compound pressure) : -199.9 to +199.9 kPa (-1.999 to +1.999 kgf/cm2, -19.98 to +19.98 psi, -1.999 to +1.999 bar, -1510 to +1537 mmHg, -59.4 to +60.5 inHg) DPH-102?(Positive pressure) : -1.050 to +1.050 MPa (-10.71 to +10.71 kgf/cm2, -152.2 to +152.2 psi, -10.50 to +10.50 bar) DPH-103?(Vacuum pressure) : +101.3 to -101.3 kPa (+1.033 to -1.033 kgf/cm2, +14.70 to -14.70 psi, +1.013 to -1.013 bar, +760 to -760 mmHg, +29.9 to -29.9 inHg)
