E3JK-DR13 Omron Photoelectric Sensor | Original & New | KMSPARE

Material ABS Sensing Mode Diffuse Reflective Model No. E3JK-DR13 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Protection IP64 Ambient temperature range (Operating) -25 .......... +55 C Ambient temperature range (Storage) -40 ......... +70 C Weight 180 g E3JK-DR13 Omron Photoelectric sensor Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 300 x 300 mm: 2.5 m Differential distance 20% max. of sensing distance Light source Infrared LED (850 nm) Power supply voltage 24 to 240 VAC±10% 50/60 Hz 24 to 240 VDC±10% ripple (p-p) 10% max. Power consumption 2 W max. Control output Relay output (SPDT) 250 VAC 3 A (cos?= 1) max. 5 VDC 10 mA min.
