E3JK-RP11 Omron Photoelectric Sensor | Original & New | KMSPARE

Material ABS Model No. E3JK-RP11 Brand Omron Product Type Sensor Sensor type Photoelectric Sensor Current 35 mA Accuracy 100 % Ambient temperature range (Operating) -25 ......... +55 C Ambient temperature range (Storage) -40 .........+70 C Color Black Voltage 10 - 30 V Response time 1 ms Control Output PNP Current 30 mA E3JK-RP11 Omron Photoelectric sensor Shape Square type Sensing method Retro-reflective without M.S.R. function Sensing distance When using the E39-R1: 100 mm to 7 m When using the E39-R2: 100 mm to 11 m Standard sensing object Opaque: 75 mm dia. min. Directional angle 1.5 ° min. Light source Red LED (624 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 30 mA max. Control output PNP open collector 30 VDC max. 100 mA max.
