E3JK-TP13 Omron Photoelectric Sensor | Original & New | KMSPARE

Material PVC Model No. E3JK-TP13 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Color Black Weight 300 g Ambient temperature range (Operating) -40 ......... +70 C Ambient temperature range (Operating) -25 ......... +55 C Voltage 10 - 30 V Accuracy 100 % E3JK-TP13 Omron Photoelectric sensor Shape Square type Sensing method Through-beam type Sensing distance 40 m Standard sensing object Opaque: 17 mm dia. min. Directional angle Emitter: 3 ° min. Receiver: 3 ° min. Light source Infrared LED (850 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption Emitter: 25 mA max. Receiver: 15 mA max. Control output PNP open collector 30 VDC max. 100 mA max. Residual voltage: 3 V max.
