E3T-FT12 Omron Photoelectric Sensor | Original & New | KMSPARE

Material PBT Model No. E3T-FT12 Brand Omron Product Type Photoelectric Sensor Color Black Light source Red LED (650 nm) Sensing method Through-beam type Voltage 12 - 24 V Sensing Distance 500 mm Temperature -25 ...... 55 C Shape Rectangular type (Flat) Sensing method Through-beam type Sensing distance 500 mm Standard sensing object Opaque: 1.3 mm dia. min. Minimum sensing object 1.3 mm min. dia. (Opaque) Directional angle Emitter: 3 to 25 ° Receiver: 3 ° min. Light source Red LED (650 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption Emitter: 10 mA max. Receiver: 20 mA max. Control output NPN open collector 26.4 VDC max. 50 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 50 mA)
