E3T-FT13 Omron Photoelectric Sensor | KMSPARE LINK PVT LTD

Material PBT Sensing Mode Through Beam Model No. E3T-FT13 Brand Omron Product Type Sensor Ambient temperature range (Storage) -40 to 70 C Ambient temperature range (Operating) -25 to 55 Control output PNP Weight 40 g Color Black Shape Rectangular type (Flat) Shape Rectangular type (Flat) Sensing method Through-beam type Sensing distance 500 mm Standard sensing object Opaque: 1.3 mm dia. min. Minimum sensing object 1.3 mm min. dia. (Opaque) Directional angle Emitter: 3 to 25 ° Receiver: 3 ° min. Light source Red LED (650 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption Emitter: 10 mA max. Receiver: 20 mA max. Control output PNP open collector 26.4 VDC max. 50 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 50 mA) Operation mode Light-ON
