E50S8-500-6-L-5 Autonics Rotary Encoder – Industrial Incremental Encoder | KMSPARE

Material Stainless Steel Encoder Type Rotary Usage/Application Industrial Color Black Hollow Shaft Diameter 8 mm Power Supply Voltage 5 V Operating Temperature Range -10 ....... +70 C Storage Temperature Range -25......... +55 C Total Resolution 500P/R Weight (packed state) 363 g Model No. E50S8-500-6-L-5 Brand Encoder Product Type Rotary Encoders Max. response frequency 300 kHz Power supply 12- 24 V Accuracy 100 % E50S8-500-6-L-5 Shaft outer diameter : Ø8mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 70gf.cm(max. 0.00686N.m) Resolution : 500P/R Control output : Line Driver Power supply : 5VDC ±5%(ripple P-P: max. 5%) Connection type : Axial cable type Protection structure : IP50 (IEC standard)E50S8-500-6-L-5 Shaft outer diameter : Ø8mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 70gf.cm(max. 0.00686N.m) Resolution : 500P/R Control output : Line Driver Power supply : 5VDC ±5%(ripple P-P: max. 5%) Connection type : Axial cable type Protection structure : IP50 (IEC standard)
