EE-SPX613 Omron Liquid Level Photoelectric Micro Sensor – KMSPARE

Material PBT Model No. EE-SPX613 Brand Omron Product Type Sensor type Liquid Level Photoelectric Micro Sensor Voltage 12 to 24 V Weight 55 g Temperature -10 ....... 55 C Models EE-SPX613 Applicable pipe Any 6- to 13-mm-diameter pipe with a wall thickness of 1 mm that is made of FEP or any other material as transparent as FEP. Sensing object Liquids in pipes (High-viscosity liquids or liquids with floating materials may not be detected.) Light source GaAs infrared LED with a peak wavelength of 940 nm Indicator Light indicator GaP (Red LED: Peak wavelength of 700 nm) Supply voltage 12 to 24 VDC ±10%, ripple (p-p): 5% max. Current consumption Average: 30 mA max., Peak: 80 mA max. Control output NPN open collector: Load power supply voltage: 5 to 24 VDC Load current: 100 mA max. OFF current: 0.5 mA max. 100 mA load current with a residual voltage of 0.8 V max. 40 mA load current with a residual voltage of 0.4 V max
