EX-Z12B-R Panasonic Photoelectric Sensor | KMSPARE

Material PBT Accuracy 100 % Activation current 15 mm Active Area 8 mm Operating temperature -25 ....... +55 C Model No. EX-Z12B-R Brand Panasonic Product Type Sensor Sensor Type Photoelectric Sensor Color Black Weight 35 g Cable Length 2 m Protection IP67 Ambient temperature -10 ......... +55 C Product Number EX-Z12B-R Part Number EX-Z12B-R Products Name Ultra-minute Photoelectric Sensor Product details Thru-beam [Side sensing] Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), UL/c-UL Certification Output operation Dark-ON Sensing range 200 mm 7.874 in Min. sensing object ø0.5 mm ø0.02 in opaque object (Completely beam interrupted object)(Setting distance between emitter and receiver: 200 mm 7.874 in) Repeatability(perpendicular to sensing axis) 0.03 mm 0.001 in or less
