FS-N18N Keyence Optical Fiber Amplifier | KMSPARE

Voltage 10-30V Type Optical Fiber Amplifier Light Source Red LED Interface IO-Link Model Number FS-N18N Switching Frequency 50 Hz Switching Output PNP Housing M8 Housing Material Stainless Steel Degree of Protection IP54 Operating Temperature -40 to 125 Deg C No Load Supply Current 10 amp Supply voltage UB 10 - 24 V Model No. FS-N18N Color Black Weight 75 g Light source Red, 4-element LED APC ON/OFF switchable (Factory setting: OFF) Response time 50 µs (HIGH SPEED) /250 µs (FINE) /500 µs (TURBO) /1 ms (SUPER) /4 ms (ULTRA) /16 ms (MEGA) Number of interference prevention units 0 for HIGH SPEED; 4 for FINE; 8 for TURBO/SUPER/ULTRA/MEGA (When set to double, the number of interference-prevention units will be doubled.) Unit expansion Up to 16 units can be connected total (two output type is treated as two units) Rating Power voltage 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less Current Consumption Normal: 900 mW or less (36 mA max. at 24 V, 48 mA max. at 12 V)*1 Eco on mode: 800 mW or less (32 mA max. at 24 V, 39 mA max. at 12 V)*1 Eco Full mode: 470 mW or less (19 mA max. at 24 V, 23 mA max. at 12 V)
