FX-101P-CC2 Panasonic Digital Fiber Optic Sensor | KMSPARE

Voltage 10-30V Brand Panasonic Type Fiber Optics Sensor Heads Light Source Red LED Interface IO-Link Model Number FX-101P-CC2 Switching Frequency 250 kHz Switching Output PNP Housing Cable Housing Material Plastic Degree of Protection IP67 Operating Temperature -40 to 100 Deg C No Load Supply Current 10 mA Supply voltage UB 10 .... 30 V Device Short Name FX-101P-CC2 Weight 75 g Part Number FX-101P-CC2 Products Name Digital Fiber Sensor Product details Standard type [Cable set] The price of the product Please contact our office Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), UL/c-UL Listing certification Supply voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less Power consumption Normal operation: 720 mW or less (Current consumption 30 mA or less at 24 V supply voltage) ECO mode: 600 mW or less (Current consumption 25 mA or less at 24 V supply voltage) Output PNP open-collector transistor - Maximum source current: 100 mA - Applied voltage: 30 V DC or less (between output and +V) - Residual voltage: 1.5 V or less (at 100 mA source current)
