IFM O3D300 3D Sensor | Time-of-Flight Detection | KMSPARE

Temperature Range -30 DegreeC to +250 DegreeC Image resolution 3D[px] 176 x 132 Angle of aperture 3D[ Degree] 40 x 30; (nominal value without lens distortion correction) Housing rectangular Operating voltage[V] 20.4...28.8 DC; (EN 61131-2) Image sensor PMD 3D ToF-Chip Trigger 24 V PNP/NPN (IEC 61131-2 Typ 3) Total number of outputs 3 Reliable volume determination for storage and conveyor technology Non-contact dimensioning of rectangular objects such as cardboard packages or parcels Reliable measurement of height, width and length to calculate strap length and volume Reliable detection of size, orientation and position of the objects for automated storage space planning Switching outputs and Ethernet process data interface.
