IFM O3D302 3D Sensor | Time-of-Flight Detection | KMSPARE

Type of light infrared light Image resolution 3D[px] 176 x 132 Angle of aperture 3D[ Degree] 60 x 45; (nominal value without lens distortion correction) Max. reading rate [Hz] 25 Housing rectangular Application dimensioning of the object; completeness monitoring; Level monitoring; distance monitoring; volume m Operating voltage tolerance[%] -15...20 Operating voltage[V] 24 DC; (EN 61131-2) Image sensor PMD 3D ToF-Chip Trigger 24 V PNP/NPN (IEC 61131-2 Typ 3) Operating distance[mm] 300...8000 Communication interface Ethernet Reliable volume determination for storage and conveyor technology Non-contact dimensioning of rectangular objects such as cardboard packages or parcels Reliable measurement of height, width and length to calculate strap length and volume Reliable detection of size, orientation and position of the objects for automated storage space planning Switching outputs and Ethernet process data interface
