IFM UIT500 Ultrasonic Sensor | High-Precision Industrial Sensor | KMSPARE

IFM UIT500 Ultrasonic Sensor – High-Precision Detection | 4 mm Sensing Distance | IP68 Rated

The IFM UIT500 ultrasonic sensor is built for industrial-grade reliability, offering precise and contactless object detection across a wide range of materials. Whether you're monitoring clear glass, reflective metal, or dark surfaces, the UIT500 delivers unmatched performance with programmable flexibility.

🔧 Technical Specifications:

• Brand: IFM

• Model Number: UIT500

• Sensor Type: Ultrasonic

• Sensing Distance: 4 mm

• Output Type: PNP

• Output Function: Normally Open / Normally Closed (Programmable)

• Switching Mode: NO / NC

• Supply Voltage: 12 – 24 V DC

• Connection Type: M12 Connector

• Number of Wires: 2-Wire

• Body Material: Stainless Steel

• Degree of Protection: IP68

• Operating Temperature: -40°C to +105°C

• Usage: Industrial, Security Applications

✅ Key Features:

• Highly Reliable Detection: Large detection range with non-contact ultrasonic technology

• Surface-Independent: Accurately detects objects regardless of transparency, color, or texture

• User-Friendly Setup: Easily configure detection range via pushbutton or IO-Link

• Status Indicators: Clearly visible LED for real-time switching and echo feedback

• Durable & Robust: Stainless steel construction with IP68 protection – ideal for harsh environments

• Programmable Logic: Switch between NO/NC modes to suit your system requirements

Whether for safety automation, material handling, or presence detection, the IFM UIT500 ultrasonic sensor ensures high reliability and intuitive operation across all industrial environments.
