MKS3PN-220VAC Omron Power Relay – Industrial Automation | KMSPARE

Number Of Poles 4 Pole Material Plastic Usage/Application Relay Modules Model Name/Number MKS3PN-220VAC Coil Voltage 220 V Voltage Type AC Current 15 mA Relay Type Signal Relays Rated Current 15 mA Brand Omron Product type Relay Type Power Relay Coil ratings 60 Hz Weight 90 g Mounting method Socket Operating indicator LED/Mechanical indicator Degree of protection Closed type (cover) Terminal structure Plug-in terminal Coil Coil ratings 220 VAC 50 Hz 12.1 mA 220 VAC 60 Hz 10.5 mA Coil resistance 3550 ? Operate voltage (Set voltage) 80 % max. Release voltage (Reset voltage) 25 % min. (50 Hz) 30 % min. (60 Hz) Maximum voltage 110 % Power consumption Approx. 2.7 VA 50 Hz/Approx. 2.3 VA 60 Hz Contact Contact rated load 250 VAC 10 A (NO contact: Resistive load) 250 VAC 5 A (NC contact: Resistive load) 250 VAC 7 A (Inductive load (cos? = 0.4)) 30 VDC 10 A (NO contact: Resistive load) 30 VDC 5 A (NC contact: Resistive load) Max. contact voltage 250 VAC 250 VDC Max. contact current AC: 10 A DC: 10 A
