Omron Z-15GQ22 Limit Switch | High Precision Industrial Micro Switch – KMSPARE

Switch Type
Rotary
Rated Voltage
240 VAC
Model Name/Number
Z-15GQ22
Operating Frequency
50 / 60 Hz
Packaging Type
BOX
Ambient Operating Temperature
-20 ...... 75 C
Product Type
Limit Switch
Weight
142 g
Brand
Omron
Product Color
Silver
1. The above current ratings are the values of the steady-state current.
           2. Inductive load has a power factor of 0.4 min. (AC) and a time constant of 7 ms max. (DC).
           3. Lamp load has an inrush current of 10 times the steady-state current.
           4. Motor load has an inrush current of 6 times the steady-state current.
           5. The normally closed and normally open ratings of reverse hinge lever models are opposite to each other.
           6. The AC ratings of molded terminals are 125 and 250 V only.
           7. The ratings values apply under the following test conditions:
                 (1) Ambient temperature: 20±2°C
                 (2) Ambient humidity: 65±5%RH
                 (3) Operating frequency: 20 operations/min
