O1D100 IFM Photoelectric Distance Sensor

Laser protection class 2 Housing rectangular Electrical data Operating voltage[V] 18...30 DC; ("supply class 2" to cULus) Current consumption[mA] < 150 Protection class III Reverse polarity protection yes Typ. lifetime[h] 50000 Inputs / outputs Number of inputs and outputs Number of digital outputs: 2; Number of analogue outputs: 1 Outputs Total number of outputs 2 Electrical design PNP Number of digital outputs 2 Output function normally open / normally closed; (parameterisable) Max. current load per output[mA] 200 Number of analogue outputs 1 Analogue current output[mA] 4...20; (IEC 61131-2) Max. load[?] 250 Analogue voltage output[V] 0...10; (IEC 61131-2) Min. load resistance[?] 5000 Short-circuit protection yes Type of short-circuit protection pulsed Overload protection yes Detection zone Max. light spot width[mm] 15 Max. light spot height[mm] 15 Light spot dimensions refer to 10 m Background suppression[m] 0...19 Measuring/setting range Measuring range[m] 0.2...10; (white paper 200 x 200 mm 90% remission) Sampling rate[Hz] 1...50 Interfaces Communication interface IO-Link Transmission type COM2 (38,4 kBaud) IO-Link revision 1.1 SDCI standard IEC 61131-9 Profiles Smart Sensor - SSP 0 Generic Profiled Sensor Function Device identification Function Process data variable Function Device diagnosis Function Teach channel SIO mode yes Required master port type A Process data analogue 2 Process data binary 3 Min. process cycle time[ms] 5 Supported DeviceIDs Type of operation DeviceID default 806 Operating conditions Ambient temperature[°C] -10...60 Protection IP 67 Tests / approvals EMC EN 60947-5-2 Laser protection class 2 Notes on laser protection Caution: laser light Power: <= 4 mW Wave length: 650 nm pulse: 1,3 ns Do not stare into beam. Avoid exposure to the laser light. laser class: 2 EN / IEC60825-1:2007 EN / IEC60825-1:2014 Complies with 21 CFR 1040.10 except for conformance with IEC 60825-1 Ed. 3, as described in Laser Notice No. 56, dated May 8, 2019. MTTF[years] 182 Mechanical data Weight[g] 243.5 Housing rectangular Dimensions[mm] 59 x 42 x 52 Materials housing: diecast zinc; front pane: glass; LED window: PC Lens alignment side lens Displays / operating elements Display switching status 2 x LED, yellow operation LED, green distance value, programming alphanumeric display, 4-digit Accessories Accessories (optional) Protective cover, E21133 Remarks Remarks For more information about the measuring range / application please refer to the operating instructions. Pack quantity 1 pcs. Electrical connection Connection Connector: 1 x M12; coding: A Other data Parameter Setting range Factory setting Uni mm, m, inch mm OU1 Hno, Hnc, Fno, Fnc Hno SP1 [mm] 200...9999 1000 nSP1 [mm] 200...9999 800 FSP1 [mm] 200...9999 1200 OU2 Hno, Hnc, Fno, Fnc, I, U I SP2 [mm] 200...9999 2000 nSP2 [mm] 200...9999 1800 FSP2 [mm] 200...9999 2200 ASP [mm] 0...9999 0 AEP [mm] 0...9999 9999 rATE [Hz] 1...50 50 dS1 [s] 0...0.1...5 0 dr1 [s] 0...0.1...5 0 dS2 [s] 0...0.1...5 0 dr2 [s] 0...0.1...5 0 dFo [s] 0...0.1...5 0 dIS d1...3 ; rd1...3; OFF d3 repeatability/accuracy distance repeatability of the measured values accuracy white (90 % remission) grey (18 % remission) white (90 % remission) grey (18 % remission) 200...1000 mm ± 5.0 mm ±7.5 mm ± 15.0 mm ± 18.0 mm 1000...2000 mm ± 5.5 mm ±10.0 mm ± 15.0 mm ± 20.0 mm 2000...4000 mm ± 17.5 mm ±22.5 mm ± 25.0 mm ± 32.0 mm 4000...6000 mm ± 27.5 mm ±40.0 mm ± 35.0 mm ± 50.0 mm 6000...10000 mm ± 60.0 mm ± 70.0mm Sampling rate 50 Hz Extraneous light on the object < 40 klx repeatability/accuracy distance repeatability of the measured values accuracy white (90 % remission) grey (18 % remission) white (90 % remission) grey (18 % remission) 200...1000 mm ± 16.5 mm ±16.5 mm ± 26.5 mm ± 26.5 mm 1000...2000 mm ± 16.5 mm ±16.5 mm ± 26.5 mm ± 26.5 mm 2000...4000 mm ± 30.0 mm ±37.0 mm ± 40.0 mm ± 47.0 mm 4000...6000 mm ± 37.0 mm ±57.0 mm ± 47.0 mm ± 67.0 mm 6000...10000 mm ± 75.0 mm — ± 85.0mm — Sampling rate 50 Hz Extraneous light on the object 40...100 klx repeatability/accuracy distance repeatability of the measured values accuracy white (90 % remission) grey (18 % remission) white (90 % remission) grey (18 % remission) 200...1000 mm ± 4.0 mm ±4.5 mm ± 14.0 mm ± 15.0 mm 1000...2000 mm ± 4.5 mm ±6.0 mm ± 14.5 mm ± 16.0 mm 2000...4000 mm ± 13.5 mm ±14.5 mm ± 23.5 mm ± 24.0 mm 4000...6000 mm ± 19.0 mm ±21.0 mm ± 29.0 mm ± 31.0 mm 6000...10000 mm ± 37.0 mm – ± 47.0mm – Sampling rate 1 Hz Extraneous light on the object < 40 klx repeatability/accuracy distance repeatability of the measured values accuracy white (90 % remission) grey (18 % remission) white (90 % remission) grey (18 % remission) 200...1000 mm ± 10.0 mm ± 10.0 mm ± 20.0 mm ± 20.0 mm 1000...2000 mm ± 10.0 mm ± 10.0 mm ± 20.0 mm ± 20.0 mm 2000...4000 mm ± 17.0 mm ± 18.0 mm ± 27.0 mm ± 28.0 mm 4000...6000 mm ± 22.0 mm ± 25.0 mm ± 32.0 mm ± 35.0 mm 6000...10000 mm ± 37.0 mm – ± 47.0mm – Sampling rate 1 Hz Extraneous light on the object < 40...100 klx - - Range on black object (6 % remission) <= 4000 mm - - The values apply at constant ambient conditions 23 °C / 960 hPa minimum power-on time in minutes 10 Reliable optical distance measurement with high ranges up to 10 m Two switching outputs, one of them programmable as analogue output Scalable measuring range and window function Use in applications with background suppression Excellent price/performance ratio
