40.52.9.024.0000 FINDER Relay

Voltage 24 vdc Type of relay electromagnetic Contact current max 15A Switched voltage max. 220V DC, max. 400V AC Body dimensions 29x12.4x25mm The manufacturer of the relay with the designation 40.52.9.024.0000 is FINDER. It is an electromagnetic miniature relay with a DPDT contact configuration. The nominal coil voltage is 24V DC, and the maximum contact current is 15A. Under resistive load, the contacts can carry a current of 8A at 250V AC or 30V DC. The relay is capable of switching voltages up to 220V DC or 400V AC. The relay can be mounted on a PCB or on a socket. The coil resistance is 900?, and the coil power consumption is 650mW. The relay operates in temperatures ranging from -40 to 85°C. The product belongs to the relay series designated as 40.52. The contact material is AgNi. The pin pitch is 5mm. The coil current is 27mA.
