HT23/2 50138442 Leuze Diffuse Sensor

Wavelength 645 nm Focal distance 200 mm Adjustment range 15 ... 400 mm Cable length 2,000 mm Number of conductors 3 -wire Diffuse reflection principle with background suppression The Leuze HT23/2 Diffuse sensor with background suppression (Part No. 501328442) is an innovative solution for industrial automation.The Leuze HT23/2 Diffuse Sensor, part of Series 23, employs diffuse reflection with background suppression for precise detection. It features an adjustable range from 15 to 400 mm. The diffuse sensor has guaranteed ranges: 0.005 to 0.4 meters for white surfaces, 0.01 to 0.3 meters for gray, and 0.015 to 0.2 meters for black. Utilizing a red LED light source with a 645 nm wavelength and a focused beam path, the sensor ensures accuracy. With a transistor NPN switching element and a switching frequency of 1,000 Hz, it provides rapid response times. The sensor's compact PC-ABS plastic housing measures 11.4 mm x 34.2 mm x 18.3 mm, weighing 50 g, making it easy to install.
