8.KIH50.8351.0200 Kubler Rotary Encoder

Encoder Type Rotary Material Stainless Steel Usage/Application Industrial Color Silver Power Supply Voltage 5 ....... 30 V Operating Temperature Range -10 ....... 50 C Storage Temperature Range -20 ....... 75 C Weight (packed state) 107 g Model No. 8.KIH50.8351.0200 Brand Kubler Product Type Rotary Encoder Dimension 50 mm Max. rotational spee 6.00 mm The economical sensor solution. The Sendix KIS50 / KIH50 incremental standard encoders with optical sensors are designed for highest economic efficiency and are available up to a resolution of 5000 pulses per revolution. Special details from the sophisticated Sendix technology can be found in these encoders. This results in a high resistance to vibration and installation error. It sets new standards in cost-sensitive applications. They are ideal for standard applications and for use in simple machines. Mechanical Dimension Ø 50 mm Shaft type 8 mm hollow shaft, through 10 mm hollow shaft, through 12 mm hollow shaft, through 14 mm hollow shaft, through 15 mm hollow shaft, through Flange type Ø 50.80 mm Ø 63.00 mm Ø 65.00 mm Working temperature -20 °C ... +70 °C
