8.KIH50.8351.0250 Kubler Rotary Encoder

Material Stainless Steel Encoder Type Rotary Usage/Application Industrial Color Silver Power Supply Voltage 5 ....... 30 V Operating Temperature Range -10 ........ 50 C Storage Temperature Range -20 ..... 70 C Total Resolution 10 Weight (packed state) 409 g Model No. 8.KIH50.8351.0250 Brand Kubler Product Type Rotary Encoder The encoders Sendix Base KIS50 / KIH50 offer a protection level up to IP65 and can be used with temperatures from -20 °C up to +70 °C. They are ideal for use in standard applications and in simple machines. The Sendix Base KIS50 / KIH50 family also features our well proven Safety-LockTM system, allowing higher tolerance of possible installation errors and increasing the overall performance of this encoder. Maximum speed 6000 min-1 for option 9888 8000 min-1 3000 min-1 (continuous) Mass moment of inertia shaft version approx. 1.8 x 10-6 kgm2 hollow shaft version approx. 6 x 10-6 kgm2 Starting torque at 20 °C [68 °F] < 0.01 Nm Shaft load capacity radial 80 N axial 40 N Weight approx. 0.4 kg [14.11 oz] Protection acc. to EN 60529 IP65 Working temperature range -20 °C ... +70 °C [-4 °F ... +158 °F] for option 9888 -40 °C ... +80 °C [-40 °F ... +176 °F] Material shaft stainless steel Shock resistance acc. to EN 60068-2-27 1000 m/s2 , 6 ms
