8.KIH50.8351.0600 Kubler Rotary Encoder

Material Stainless Steel Encoder Type Rotary Usage/Application Industrial Color Silver Power Supply Voltage 10 -30 V Operating Temperature Range -40 ....... 70 C Output Circuit PNP Storage Temperature Range -10 ...... 55 C Model No. 8.KIH50.8351.0600 Brand Kubler Product type Rotary Encoder Weight 400 g Maximum speed 6000 min-1 for option 9888 8000 min-1 3000 min-1 (continuous) Mass moment of inertia shaft version approx. 1.8 x 10-6 kgm2 hollow shaft version approx. 6 x 10-6 kgm2 Starting torque at 20 °C [68 °F] < 0.01 Nm Shaft load capacity radial 80 N axial 40 N Weight approx. 0.4 kg [14.11 oz] Protection acc. to EN 60529 IP65 Working temperature range -20 °C ... +70 °C [-4 °F ... +158 °F] for option 9888 -40 °C ... +80 °C [-40 °F ... +176 °F] Material shaft stainless steel Shock resistance acc. to EN 60068-2-27 1000 m/s2 , 6 ms for option 9888 2000 m/s2 , 6 ms Vibration resistance acc. to EN 60068-2-6 100 m/s2 , 10 ... 2000 Hz for option 9888 200 m/s2 , 10 ... 2000 Hz
