UNI-808-ZDA-48-25-00 UNISON Solid State Relay

Number of Poles 3 Pole Parts Relay Board Model Name/Number 808 ZDA 48 25 00 Usage/Application Industrial Channels 2 Color Black Voltage Type AC Power 50 Amps Material PVC Operating Temp. -10 .....55 C Relay Current 15 mA I Deal In New Only Fix Input 8 - 28 V DC Max load 15 A Current Rating 10 kA Control Input 4 - 32 V Slim width 23.6 mm design. Fault detection SSR Fault type : Load open or short/SSR short/MCB trip Fault indication: Red LED and Optocoupler o/p. Control Input : 4-32VDC/6-18mA, Green LED Fix Input: 8-28VDC/5-25mA Output : 80-580VAC (47-63 Hz), 50 Amp Body & I/P. to O/P. insulation : 2.5kV for 1min Short Circuit Protection by "B" Curve DP MCB Resistive load Max 15 A SC protect by 16 A DP MCB Short Circuit Current Rating : 10kA for <3mS
