BES-516-300-S289-BO-D-00,07 BALLUFF Inductive Sensor

Usage for Industrial Current 10mA Switching Function Normally open (NO) Output PNP Sensing Distance 5 mm Voltage 24 V Detectable Object METAL Material Stainless Steel Dimension Dia-8mm,Length-34mm Temperature Range -25 To 80 Deg C Special Feature Pressure Rated Inductive Sensor Pressure Range 100 Bar Protection IP65 Supply Voltage 10-30VDC DimensionØ 8 x 34 mmStyle HousingM8x1Installationfor flush mountingRange1.5 mmSwitching outputPNP normally open (NO)Switching frequency4000 HzHousing materialStainless steelMaterial sensing surfaceCeramicConnectionLeads, 0.07 m, PVCOperating voltage Ub10...30 VDCAmbient temperature-25...80 °CPressure rating max.100 barIP ratingIP65Approval/ConformityCE UKCA cULus WEEE
