BL13-TDT Autonics Photoelectric Sensor

Material Stainless Steel Sensing Mode Through-beam Model No. BL13-TDT Brand Autonics Product Type Sensor Sensor type Photoelectric Sensor Accuracy 100 % Weight 50 g Control Output NPN Ambient temperature -10 ......... +55 C BL13-TDT Sensing type : Through-beam type Applicable pipe : Using binding band: Ø6 to 13mm, Using protection bracket: Ø12.7mm (1/2 inch) transparent pipe in 1mm thickness (FEP (fluoroplastic) or with equivalent transparency) Standard sensing target : Liquid in a pipe Light source : Infrared LED(950nm) Response time : Max. 2ms Power supply : 12-24VDC ±10%(ripple P-P: max. 10%) Operation mode : Light ON/Dark ON(set by button) Control output : NPN open collector
