BS5-P1ML-P Autonics Photo Micro Sensor

Sensing Mode Through-beam Material PBT Model No. BS5-P1ML-P Brand Autonics Product Type Sensor Sensor type Photomicro Sensor Color Black Weight 30 g Accuracy 100 % BS5-P1ML-P Operation method : Push Button Type Power supply : 12-24VDC ±10%(ripple P-P: max. 10%) Operation mode : Light ON(output OFF when button ispushed) Control output : PNP open collector Operation method Push Button Type Button operation_Stop position 5.0±0.4mm Button operation_Output switching position 4.0±0.5mm Button operation_Operation limit position Max. 0mm Light source Infrared LED(940nm) Power supply 12-24VDC ±10%(ripple P-P: max. 10%) Current consumption Max. 35mA
