BUM4-40D-W-4M-A Autonics Photoelectric Sensor

Sensing Mode Through-beam Material PBT Model No. BUM4-40D-W-4M/A Brand Autonics Product Type Sensor Sensor Type Photoelectric Sensor Sensing type Sensing Channel Sensing distance 40mm Response time 1 ms Ambient temperature -25 ........... +65 C Protection structure IP65 Accuracy 100 % Sensing distance 40 mm BUM4-40D-W-4M/A Sensing type : Through-beam type Sensing Channel : 4-channel Sensing distance : 40mm Sensing target : Opaquematerial of min. Ø4mm Light source : Infrared LED(940nm) Power supply : 18-35VDC ±10%(ripple P-P: max. 10%) Operation mode : Dark ON Control output : NPN open collector(individual 4 outputs)
