CBN5-F46-E3 P&F Capacitive Sensor

Sensing Distance 15 mm Sensor Type Capacitive Usage For Industrial Body Material Stainless Steel Brand P&F Model Name/Number CBN5-F46-E3 Usage/Application Industrial Output Type PNP Switching Frequency 10 Hz Product Type Sensor Material PBT Power supply voltage 10- 30 V Accuracy 100 % Maximum Switching Current 15 mA Height 5 mm Width 50 mm Length 25 mm Capacitive sensor CBN5-F46-E3 5 mm non-flush 3-wire DC Flat housing Mounting slots for cable ties Thru-holes for screw mounting
