CJ15+U1+A2 P&F Capacitive Sensor

Switching Mode NC Sensing Distance 10 mm Usage For Industrial Body Material Stainless Steel Brand P&F Output Type PNP Sensor Type Capacitive Sensor Supply Voltage 10 to 30 V DC Model Name/Number CJ15+U1+A2 Product Type Sensor Switching Frequency 10 Hz Usage/Application Industrial Connection Type Cable Number of Wires 2 Wire Response frequency 10 Hz Body Style Cylindrical Power supply voltage 10 ...... 30 V Installation Flush Degree of Protection IP67 Operating Temperature -40 to 105 Deg C General specifications Switching function complementary Output type PNP Rated operating distance sn 15 mm Installation flush Output polarity DC Assured operating distance sa 0 ... 10.8 mm Output type 4-wire Nominal ratings Installation conditions B 15 mm C 30 mm F 80 mm Operating voltage UB 10 ... 30 V DC Switching frequency f 0 ... 10 Hz Reverse polarity protection reverse polarity protected Short-circuit protection pulsing 1 Release date: 2024-05-27 Date of issue: 2024-05-28 Filename: 001604_eng.pdf
