CP1L-M40DT-A Omron PLC

Power 240V AC Mounting Type Panel Mount Output Type Relay Ambient Storage Temperature Range -25 ...... 55 C Operating Load Voltage Range 12 ..... 24 V Brand Omron Ambient Operating Temperature Range 55 C Rated Input Voltage Range 24 V Usage/Application Industrial Number of Inputs 14 Digits Degree of Protection IP20 Model No. CP1L-M40DT-A Product Type PLC Weight 550 g Frequency 50 / 60 Hz Type AC power supply models DC power supply models Model CP1L-[][][]-A CP1L-[][][]-D Power supply 100 to 240 VAC 50/60 Hz 24 VDC Operating voltage range 85 to 264 VAC 20.4 to 26.4 VDC Power consumption 50 VA max. (CP1L-M60/-M40/-M30[][]-A) 30 VA max. (CP1L-L20/-L14/-L10[][]-A) 20 W max. (CP1L-EM40/-EM30/-M60/-M40/ -M30[][]-D) 13 W max. (CP1L-EL20/-L20/-L14/ -L10[][]-D) Inrush current * 100 to 120 VAC inputs: 20 A max. (for cold start at room temperature) 8 ms max. 200 to 240 VAC inputs: 40 A max. (for cold start at room temperature), 8 ms max. 30 A max. (for cold start at room temperature) 20 ms max. External power supply 300 mA at 24 VDC (CP1L-M60/-M40/ -M30[][]-A) 200 mA at 24 VDC (CP1L-L20/-L14/ -L10[][]-A) None
