CP2E-N40DT-A Omron PLC

Power 24V DC Mounting Type Panel Mount Output Type Digital Dimensions (H x D x W) 90mm x 80mm x 86mm Ambient Storage Temperature Range -20 ..... 75 C Brand Omron Rated Input Voltage Range 240 V Display Type LCD Usage/Application Industrial Number of Inputs 14 Digits Model No. CP2E-N40DT-A Supply voltage 100 - 240 V Product Type PLC . Total of 110 mm with mounting brackets. *2. Excluding cables. *3. Use the external power supply to power input devices. Do not use it to drive output devices. *4. This is the rated value for the maximum system configuration. Use the following formula to calculate power consumption for CPU Units with DC power. Formula: DC power consumption = (5V current consumption × 5 V/70% (internal power efficiency) + 24V current consumption) × 1.1 (current fluctuation factor) The above calculation results show that a DC power supply with a greater capacity is required. Note: 1. The Expansion I/O Units and Expansion Units work under the same conditions as the CPU Units unless otherwise specified.
