D4JL-2RFA-C5 Omron Safety Switch

Switch Type Plunger Rated Voltage 240 VAC Model Name/Number D4JL-2RFA-C5 Operating Frequency 50 /60 Hz Ambient Operating Temperature -25 ........ +55 C Operating speed 0.05 to 0.5 m/s Operating frequency 30 operations/minute max. Direct opening force *4 60 N min. (EN60947-5-1) Direct opening travel *4 15 mm min. (EN60947-5-1) Holding force (Fzh) *5 3,000 N min. Contact resistance 25 m? max. (per contact) Minimum applicable load *6 1 mA resistive load at 5 VDC (N-level reference value) Rated insulation voltage (Ui) 300 V (EN60947-5-1) Rated frequency 50/60 Hz
