D4JL-4NFA-C5 Omron Safety Switch

Switch Type Plunger Rated Voltage 240 VAC Model Name/Number D4JL-4NFA-C5 Packaging Type Box Ambient Operating Temperature -10 ....... +55 C Insulation resistance 100 M? min. (at 500 VDC) Contact gap 2 × 2 mm min. Vibration resistance Malfunction 10 to 55 Hz, 0.75 mm single amplitude Shock resistance Destruction 1,000 m/s2 min. Malfunction 80 m/s2 min. Conditional short-circuit current 100 A (EN60947-5-1) *7 Conventional free air thermal current (Ith) 10 A (between terminals 12 and 41), 3 A (between all other terminals) (EN60947-5-1) Ambient operating temperature -10 to +55°C (with no icing) Ambient operating humidity 95% max. Weight Approx. 650 g (D4JL-4NFA-C7-01)
