D4N-2131 Omron Limit Switch

Rated Voltage 240 VAC Model Name/Number D4N-2131 Packaging Type Box Ambient Operating Temperature -25 ........ +75 C Product Type Limit Switch Weight 135 g Switching Frequency 50 / 60 Hz Operating Accuracy Block 100 % Degree Of Protection IP67 Accuracy 100 % Brand Omron Switch Type Rotary Actuator Plunger Operating mechanism Snap action ctuator Plunger 6 dia. Resin plunger Frequency 50/60 Hz Contact form 1NC/1NO Load General load/Micro load Conduit G1/2 Number of conduit: 1 Ambient temperature Operating: -30 to 70 ? (with no icing) Ambient humidity 95 %RH max. Permissible operating frequency 30 operations / 1 minute max. Contact resistance (Initial value) 25 m? max. Insulation resistance 100 M? min. Impulse withstand voltage Between each terminal of the same polarities: 2.5 kV Between each terminal of the different polarities: 4 kV Between each terminal and non-live-metallic part: 6 kV Durability Mechanical: 15,000,000 operations min. Vibration resistance Malfunction: 10 to 55 Hz, 0.75 mm single amplitude Shock resistance Destruction: 1000 m/s2 Malfunction: 300 m/s2 Degree of protection IP67
