D4N-2132 Omron Limit Switch

Switch Type Plunger Model Name/Number D4N-2132 Operating Frequency 50 / 60 Hz Ambient Operating Temperature -10 ....... +55 C Packaging Type Box Permissible operating frequency 30 operations / 1 minute max. Contact resistance (Initial value) 25 m? max. Insulation resistance 100 M? min. Impulse withstand voltage Between each terminal of the same polarities: 2.5 kV Between each terminal of the different polarities: 4 kV Between each terminal and non-live-metallic part: 6 kV Durability Mechanical: 15,000,000 operations min. Vibration resistance Malfunction: 10 to 55 Hz, 0.75 mm single amplitude Shock resistance Destruction: 1000 m/s2 Malfunction: 300 m/s2 Degree of protection IP67 Classification of protection against electric shock Class II (Double insulation)
