D4NL-2AFA-BS Omron Safety Switch

Switch Type Plunger Rated Voltage 240 VAC Model Name/Number D4NL-2AFA-BS Ambient Operating Temperature -25 ...... +70 C Packaging Type Box Insulation resistance 100 M? min. (at 500 VDC) Contact gap 2 × 2 mm min. Vibration resistance Malfunction 10 to 55 Hz, 0.75 mm single amplitude Shock resistance Destruction 1,000 m/s2 min. Malfunction 100 m/s2 min. Conditional short-circuit current 100 A (EN60947-5-1) Conventional free air thermal current (Ith) 10 A (EN60947-5-1) Ambient operating temperature -10 to 55°C (with no icing) Ambient operating humidity 95% max. Weight Approx. 370 g (D4NL-1AFA-B)
