DBK+4/M12/3BEE/M18-E+S Microsonic Ultrasonic Sensor

ensing Distance 15 mm Usage For Industrial Brand Microsonic Body Material Stainless Steel Output Type PNP Supply Voltage 12 to 24 V DC Sensor Type Ultrasonic Sensor Part Number DBK+4/M12/3BEE/M18-E+S Model Name/Number DBK+4/M12/3BEE/M18-E+S Product Type Sensor Switching Frequency 60 Hz Usage/Application Industrial Connection Type Cable Response frequency 50 /60 Hz Power supply voltage 10 ...... 30 V Installation Flush Control output PNP Protection circuits IP67 Degree of Protection IP67 Operating Temperature -25 to 70 Deg C Power 5 A Switching Mode NO/NC The new dbk+4 has 3 control inputs by means of which 3 working range can be preselected. The standard working ranges covers the sheet material weight range from 20 g/m2 to 1,200 g/m2. Extremely thin materials such as Bible printing paper with a weight per unit area of less than 20 g/m2 are scanned with the use of the "Thin" setting. The "Thick" setting is available for paperboard containers and fine-corrugated card. Changes between the working ranges can be undertaken under on-going operations. A Teach-in for the material to be scanned is not necessary. If the 3 control inputs stay unconnected, then the dbk+4 operates in the standard working range. As such, a very broad material spectrum can be scanned.
