BEN300-DFR Autonics Photo Electric Sensor

Sensing Mode Diffuse Reflective Material Plastic Model Name/Number BEN300-DFR Sensing Distance 300 Mm Voltage 240 V Type of diffuse reflection; 300 mm of sensing distance; Sensing target: Translucent, opaque substance Infrared LED light source (940nm); Maximum response time: 20 ms Maximum current consumption is 4VA. Power supply specifications are 24-240VAC~ ±10% 50/60Hz, 24-240VDC ±10% (ripple P-P: max. 10%); Adjusting for sensitivity: Sensitivity adjuster; Operation mode: switch-controlled light-on/dark-on; Controlled result: Switch Storage Temperature: -25°C to 70°C, Relative Humidity: 35–85% RH; Operating Temperature: -20°C to 65°C Sensor, Photo, Diffuse Reflective, Light & Dark On, Relay Output, 24-240 VAC & VDC. Photoelectric Sensor Type AC/DC both support (BEN) Sensing type Diffuse reflective Sensing distance 300 mm Power supply 24 - 240 VDC Operation mode Light & Dark On Control output Relay contact output
