ML100-8-1000-RT/103/115 P&F Diffuse Mode Sensor

Sensing Distance 0-1000mm Brand P&F Sensor Type Diffuse Mode Sensor Model Name/Number ML100-8-1000-RT/103/115 Output Type PNP Adjustment range 100 to 1000 mm Reference target Standard white, 100 mm x 100 mm Light source LED Light type Modulated visible red light Diameter of the light spot Approx. 75 mm at a distance of 1000 mm Optical face Frontal Angle of divergence Approx. 2 Deg Ambient light limit EN 60947-5-2:2007+A1:2012 MTTF 860A Mission Time 20 A Diagnostic Coverag 0% Operation indicator LED green: power on Function indicator LED yellow, lights up with receiver lit Operating voltage 10 to 30 V DC Ripple Max 10% No-load supply current <20A Switching voltage Max. 30 V DC Switching current Max. 100 mA , resistive load Response time 0.5 ms Product standard EN 60947-5-2 Ambient temperature -30 to 60 DegC Housing width 11 mm Housing height 31 mm Housing depth 20 mm Connection 2 m fixed cable Degree of protection IP67 Housing Material Polycarbonate Features: Miniature design Easy to use Very bright, highly visible light spot Full metal thread mounting Highly visible LEDs for Power ON and switching state Not sensitive to ambient light.
