DM542E Leadshine Microstep Drive

Control Method V/F Control Input Phase Three Phase Motor Type Synchronous Brand Leadshine Output Power PNP Output Current 4.2 A Model Name/Number DM542E Usage/Application Industrial Speed Hight Speed Frequency 50 Hz Weight 391 g Peak Current 15 mA Operating Temp. -10 ...... 55 C Accuracy 100 % Series DM Voltage 24V Input Voltage 240 V ? Step & direction (PUL/DIR) control ? Input voltage 18-50VDC (recommended 24-48VDC) ? 200 KHz max pulse input frequency ? 16 microstep resolutions of 200-51,200 via DIP switches ? 8 output current settings of 1.0-4.2A via DIP Switches ? Idle current reduction to 50% or 90% selection via SW4
