DOP-107EG Delta HMI

Screen size 12 inch Mounting Type Panel Mount Display Size 22 inch Phase Single Phase Resolution 800 x 480 Pixels Control Type Touch Screen Dimensions (W) x (H) x (D) mm 184 x 144 x 50 Display Colors 65k Memory 256 Dimension 172.4 x 132.4 Model No. DOP-107EG Brand Delta Product type HMI RAM 256 Color Black Install the product in an indoor location, which is free of vapor, corrosive and inflammable gas and liquids. ? Please refer to the wiring diagram when connecting the wires. ? Ensure your HMI is correctly grounded. The grounding method must comply with the national electrical standard (please refer to NFPA 70: National Electrical Code, 2005 Ed.). ? Do not disassemble the HMI or change the wiring when power is on. ? Do not touch the power supply when power is on, or it may cause electric shock. ? When the HMI displays a low power notification and requires a battery change, please contact your local distributor or Delta Customer Service Center for the replacement. Do not change the batteries by yourself. ? This product can be used with other industrial automation equipment. Please read through this sheet carefully and install the product according to the instructions to avoid danger. ? Cleaning method: please use a dry cloth to clean the product. ? This product must be used at an altitude below 2,000 m. ? If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
