DOP-112MX Delta HMI

Mounting Type Panel Mount Screen size 12 inch Display Size 15 inch Phase Single Phase Resolution 1024 x 768 Pixels Control Type Touch Screen Dimensions (W) x (H) x (D) mm 387.7 x 295.7 x 63.5 Display Colors 65k Memory 1000 Dimension 372.4 x 283.7 Model no. DOP-112MX Brand Delta Product Type HMI Color Black RAM 1000 ROM 8 GB Temperature -15 .......... 50 C 1. The half-life of the backlight is defined as the maximum luminance being reduced by 50% when the maximum drive current is supplied to the HMI. The life of LED backlight shown here is estimated at the room temperature of 25°C with ambient humidity. 2. The withstand voltage of the isolated power circuit is 1500V peak for 1 minute. 3. The HMI power consumption is the power consumed when the HMI is not connecting with other peripheral devices. To ensure normal operation of the HMI, the recommended capacity of the power supply is 1.5 to 2 times of the specified power consumption. 4. Isolated power supply is recommended. 5. For the DOPSoft programming software of the DOP-100 series and the user manual, you can download them at 6. DOP-100 series can be used with other industrial automation equipment. Please read through this sheet carefully and install the product according to the instructions to avoid danger.
