DP-001-P Panasonic Digital Pressure Sensor

Suitable Media Gas Brand Panasonic Pressure Range 500 kPa Accuracy 100 % Response Time 2 ms Output PNP Supply Voltage 12 - 24 V Interface I/O Link Housing Material PBT Operating Temperature -25 to 70 Deg C IP Protection Class IP67 Weight 25 g Sensor Type Digital Pressure Sensor Product Type Sensor CE Marking Directive Compliance EMC Directive, RoHS Directive Type of Pressure Gauge pressure Rated Pressure Range -100.0 to +100.0 kPa Set Pressure Range -101.0 to +101.0 kPa -1.030 to +1.030 kgf/cm2 -1.010 to + 1.010 bar -14.65 to +14.65 psi -756 to +756 mmHg Pressure Withstandability 500 kPa
