DPU12A-040A Autonics Digital Power Controller

Voltage 240V AC Usage/Application Industrial Current Rating 40A Power Rating 10 KW Model Name/Number DPU12A-040A Power Consumption 40 W Phase Single Phase Type Automatic Brand Autonics Digit Display Size Single Frequency 50 / 60 Hz Accuracy 100% Operating Current 40 A Operating Voltage 240 V Mass 3 kg Number of phase Single-phase Indicator Operation / manual control indicator (green) DI, alarm / unit (V, A) indicator (red) Control input • Auto: 4-20mA / 0-20mA / 0-5VDC / 1-5VDC / 0-10VDC / voltage pulse (0/12VDC ) / no-voltage input (ON/OFF) / Communication input (RS485) • Manual: inside 10k? VR, outside 3 to 10k? VR (min. 2W) Control method • Phase control: Normal control(Non-Feedback), static voltage/static current/static power control(Feedback) • Cycle control (Z.C.): Fixed cycle control, Variable cycle control • ON/OFF control (Z.C.) Load • Phase control: resistance load, inductive load • ON/OFF, Cycle control: resistance load Output range Phase control: 0 to 98%, Cycle·ON/OFF control: 0 to 100% Power supply 220V
