DRT25C.3/L6-M12 LEUZE Dynamic Reference Diffuse Sensor

The Leuze DRT25C.3/L6-M12 (DRT25C3L6M12) sensor, part number 50141897, belongs to the 25C series and operates on the reference teach on background principle. Its operating range spans from 0.05 to 0.2 meters, with adjustment available within 50 to 200 mm. Equipped with a red LED light source emitting at a wavelength of 645 nm. The sensor ensures accurate detection. It utilizes a switching element of transistor, push-pull. The switching principles include IO-Link, light switching (PNP), or dark switching (NPN). Featuring a switching frequency of 750 Hz and a response time of 0.66 ms, the sensor offers swift and efficient performance. It functions as both a signal output and voltage supply source. Additionally, it utilizes a 4-pin male connector with A-coded encoding and M12 thread size.The sensor's housing, made of ABS plastic with a lens cover of plastic, weighs 22 g and has dimensions of 15 mm x 42.7 mm x 30 mm. Operational controls include a teach button for teach-in on a reference surface. The sensor is compatible with ECOLAB materials and supports SIO-mode. With an operational temperature range of -10 to 50 °C and a storage temperature range of -40 to 70 °C, it ensures reliable operation in various conditions. Our engineers acts.ively inputted all the required details of this sensor in accordance with the datasheet. Nevertheless, it's imperative to recognize that errors may arise during this process. Despite our sincere efforts, it's important to remain cautious. Inaccuracies can still occur nonetheless.
