DVP04TC-S Delta PLC

Communication Interface RS 485 Mounting Type Panel Mount Output Type Analog Brand Delta Usage/Application Industrial Number of Inputs 14 Digits Model No. DVP04TC-S Product Type PLC Resolution 14 Bits Accuracy 100 % Response Time 250 ms Voltage 12- 24 V Platinum Temperature Module (04TC) Centigrade (°C) Fahrenheit (°F) Power Supply Voltage 24 VDC(20.4VDC~28.8VDC) ( –15%~+20%) Analog Input Channel 4 channels per module Sensors Type J-type or K-type thermocouple Temperature Input Range J-type: -100°C~700°C K-type: -100°C~1000°C J-type: -148°F~1292°F K-type: -148°F~1832°F Digital Conversion Range J-type: K-1000~K7000 K-type: K-1000~K10000 J-type: K-3280~K12920 K-type: K-1480~K18320 Resolution 14 bits(0.1°C) 14 bits(0.18°F) Overall Accuracy ±0.5% of full scale of 25°C(77°F), ±1% of full scale during 0~55°C (32~131°F) Response Time 250 ms × channels Isolation Method Isolation between digital and analog circuitry. There is no isolation between channels. Digital Data Format 2's complement of 16-bit, (13 Significant Bits) Average Function Yes (CR#2~CR#5 may be set and the range is K1~K4096)
