DVP32SM11N Delta PLC

Communication Interface RS 485 Mounting Type Panel Mount Output Type Analog Pulse Transmission Output 30 mA Brand Delta Usage/Application Industrial Number of Inputs 14 Digits Degree of Protection IP67 Model No. DVP32SM11N Product Type PLC Weight 70 g Color White Voltage 5 - 24 V Model Item DVP32SM11N DVP32SN11TN Power supply voltage 24V DC (-15% ~ 20%) (with DC input polarity reverse protection) Motion specification Within 5ms of the momentary power loss, the device will keep on operating. Power consumption 1W 1.5W Insulation resistance ?5 M? (all I/O point-to-ground: 500V DC) Noise immunity ESD (IEC 61131-2, IEC 61000-4-2): 8KV Air Discharge EFT (IEC 61131-2, IEC 61000-4-4): Power Line: 2KV, Digital I/O: 1KV, Analog & Communication I/O: 1KV Damped-Oscillatory Wave: Power Line: 1KV, Digital I/O: 1KV RS (IEC 61131-2, IEC 61000-4-3): 26MHz ~ 1GHz, 10V/m Earth The diameter of grounding wire shall not be less than that of L, N terminal of the power. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) Operation/storage environment Operation: 0ºC ~ 55ºC (temperature); 50 ~ 95% (humidity); pollution degree 2 Storage: -40ºC ~ 70ºC (temperature); 5 ~ 95% (humidity) Shock/vibration immunity International standards: IEC1131-2, IEC 68-2-6 (TEST Fc)/IEC1131-2 & IEC 68-2-27 (TEST Ea)
