DW-AD-509-M30-390 CONTRINEX Inductive Sensor

Sensing Distance 20 mm Usage For Industrial Output PNP Voltage 24 V Current 10mA Switching Function Normally open (NO) Brand Contrinex Sensor Type Inductive Sensor Model Name/Number DW-AD-509-M30-390 Product Type Sensor Usage/Application Industrial Response frequency 200 Hz Power supply voltage 10 ..... 30 V Protection circuits IP64 Power 10 A Maximum Switching Current 12 mA Ambient operating temperatur -25 ........ 70 C Time delay before availability 20 ms Cable length max 300 m Accuracy 100 % Body Material Stainless Steel Material Plastic Supply voltage range (UB) Mounting Residual ripple ? 20% UB Housing material Power consumption (no-load) Sensing face material Max. load at voltage output Max tightening torque Max. load at current output Ambient operating temperature Bandwidth Enclosure rating Time delay before availability Weight (cable / connector) see page 2 Recovery time Shock and vibration IEC 60947-5-2 Short-circuit protection ü Voltage reversal protection ü Cable length max. ? 300 m Note: all data measured according to IEC 60947-5-2 standard with UB= 20…30VDC, TA= 23°C ± 5°C. DW-AD-509-M30-390 DW-AD-509-M30-320 DW-AS-509-M30-390 DW-AS-509-M30-320 ü Long sensing range ü Outstanding accuracy and temperature stability ü Resolution in µm range ü Exceptional priceperformance ratio ü Current or voltage output ü IP67 546 y DW-Ax-509-M30-3x0 M30 20 mm Quasiembeddable 20 mm ± 0.02 mm ? 0.41 µm 60 x 60 x 1 mm3 , FE360 15...30 VDC Chrome-plated brass Quasi-embeddable PBTP 70 Nm -25...+70°C IP67 ? 12 mA ? 15 mA 20 ms ANALOG OUTPUT ? 1.55 µm 0.4k? (Ub=15V) / 1k? (Ub=30V) 200 Hz 50 ms
